Design:
Pro CAD Consult works with CAD software from the following vendors:
EPLAN Software & Service:
EPLAN Electric P8 2.6 - 2.9, EPLAN Electric P8 2023 & 2024
IGE+XAO GROUP | ETAP:
SEE Electrical V8R2, V8R3, V8R4 & SEE Electrical Expert V5R1
PC | SCHEMATIC:
PC | Automation V22, V23, V24 & PC | Cabledim V3.2
Our CAD software is always updated to the latest version.
We perform electrical documentation and electrical design according to:
| DS/EN IEC 60079-0:2018 | Explosive atmospheres - Del 0: Equipment - Generelle requirements |
| DS/EN 60079-1:2014 | Explosive atmospheres - Del 1: Equipment protection by flameproof enclosures "d" |
| DS/EN 60079-7:2015 | Explosive atmospheres - Del 7: Equipment protection by increased security "e" |
| DS/EN IEC 60079-10-1:2021 | Explosive atmospheres - Del 10-1: Classification of areas - Explosive gas atmospheres |
| DS/EN 60079-10-2:2015 | Explosive atmospheres - Del 10-2: Classification of areas - Explosive dust atmospheres |
| DS/EN 60079-11:2012 | Explosive atmospheres - Del 11: Equipment protection by intrinsic safety "i" |
| DS/EN 60079-14:2014 | Explosive atmospheres - Del 14: Electrical installations design, selection and erection |
| DS/EN 60079-17:2014 | Explosive atmospheres - Del 17: Electrical installations inspection and maintenance |
| DS/EN 60204-1:2018 | Safety of machinery - Electrical equipment of machines - Part 1: General requirements |
| DS/HD 60364-1:2008 | Low voltage electrical installations - Part 1: Fundamental principles, assessment of general characteristics, definitions |
| DS/EN 60909-0:2016 | Short-circuit currents in three-phase a.c. systems - Part 0: Calculation of currents |
| DS/EN 61082-1:2015 | Preparation of documents used in electrotechnology - Part 1: Rules |
| DS/EN 61355-1:2008 | Classification and designation of documents for plants, systems and equipment - Part 1: Rules and classification tables |
| DS/EN IEC 61439-1:2021 | Low voltage switchgear and controlgear assemblies - Part 1: General rules |
| DS/EN 81346-1:2009 | Industrial systems, installations and equipment and industrial products - Structuring principles and reference designatinos - Part 2: Basic rules |
| DS/EN IEC 81346-2:2019 | Industrial systems, installations and equipment and industrial products - Structuring principles and reference designatinos - Part 2: Classification of objects and codes for classes |
| UL508A | STANDARD FOR SAFETY Industrial Control Panels |
| m.m. | |
| Our standards / norms is always updated to latest version. | |
